Workshopservices
In-house repair, machining and balancing for critical rotating equipment, delivered from TurboDyne's Al-Jubail workshop.
100 t
MAX. ROTOR WEIGHT
6
CORE SERVICE DISCIPLINES
Al-Jubail
IN-KINGDOM FACILITY
01Capabilities
Complete workshop support for critical rotating equipment.
TurboDyne brings rotor repair, shaft rectification, precision machining, inspection, assembly and dynamic balancing together at its Al-Jubail facility.
- 01
Rotor repair & refurbishment
Repair and restoration of critical rotors to recover condition and return equipment to service.
- Rotor restoration
- 02
Bend removal & shaft rectification
Precision straightening and rectification to restore shaft geometry and serviceability.
- Shaft correction
- 03
Machining services
Precision machining of critical components to support repair and refurbishment scopes.
- Precision machining
- 04
NDT & life assessment
Non-destructive inspection and residual-life assessment to establish component condition and support repair decisions.
- Condition assessment
- 05
Assembly & testing
Assembly and performance verification before rotating equipment is returned to service.
- Performance verification
- 06
Dynamic balancing
High- and low-speed dynamic balancing for rigid and flexible rotors, with capacity up to 100 tons.
- 100-ton capacity
02In-house manufacture
Proven capability in large-scale rotor manufacture.
TurboDyne designed and manufactured this 21.5 MW steam turbine rotor: evidence of the engineering and manufacturing capability behind its workshop services.
- 21.5 MW
- RATING
- 6,310 rpm
- OPERATING SPEED
- 6.5 m
- ROTOR LENGTH
- 1.60 m
- MAXIMUM DIAMETER
- 4,500 kg
- ROTOR WEIGHT
03Rotor balancing
Balancing capability for rotors up to 100 tons.
Dedicated low-speed and vacuum high-speed systems cover rigid and flexible rotors. Both systems are rated for a maximum rotor weight of 100 tons.
SCHENCK H100T
100TONMax. rotor weight
- Mobile
- Machine configuration
- Low-speed
- Balancing method
Mobile low-speed balancing for heavy-duty rotating assemblies.
ABRO HR25K / ISO (100K)
100TONMax. rotor weight
- Vacuum
- Operating environment
- High-speed
- Balancing method
Vacuum high-speed balancing of rigid and flexible rotors under controlled conditions.
04The overhaul
How equipment moves through the workshop.
- 01
As received
The equipment is received at the Al-Jubail workshop and the agreed service scope is confirmed.
- 02
Disassembly
The rotating assembly is carefully prepared for inspection and workshop work.
- 03
Inspection & assessment
Non-destructive inspection and residual-life assessment establish component condition and guide the repair scope.
- 04
Repair & rectification
Rotor restoration, shaft correction and precision machining are carried out as required by the agreed scope.
- 05
Dynamic balancing
The rotating assembly is balanced using the appropriate low-speed or vacuum high-speed system.
- 06
Assembly
Components are assembled in preparation for final verification.
- 07
Testing & release
Performance is verified before the equipment is released from the workshop.
Industries
Industries we serve
Oil & Gas
Power Generation
Mining
Steel & Cement
Petrochemical & Fertilizers
Water
Defence & Military
Plan a repair or balancing scope
Share the equipment type, component condition, available inspection information and required schedule. For rotor balancing, include the rotor weight and dimensions so the Al-Jubail team can assess the appropriate workshop scope.
